Description
2UUL PC01 POWER MAX 200W Multi-Port Charger and 4.5A 24V Adjustable Voltage Power Supply All in One Repair Station for Mobile Phone iPad Laptops. With wireless charging, USB-A Type-C PD QC fast charging port, digital display and curve display.

Features:
1. Precise detection, accurately detect mA level real-time curve, 0-24V voltage adjustable.
2. 200W maximum output power, single port maximum 65W, support mobile phones iPad and laptops.
3. Supports wireless charging, digital display and curve display.

Instructions:
1. Short press "POWER" to switch the interface.
2. Long press "POWER" to enter Voltage Regulation Mode, a green cursor will appear.
3. Short press to switch units, and the knob to adjust numbers.

Product Parameters:
Name: 2UUL PC01 Power Max Electric Rubik's Cube
Input: 100-240V
Regulating Range: 0-24V 4.5A(MAX)
Maximum Output for Single Port Charging: 65W
Product Maximum Output: 200W
Product Size: 117x103x95mm
Package Size:170*130*106mm
Gross Weight: 740g
Net Weight: 515g

2UUL PC01 Power Max Electric Rubik's Cube Multi-Port Charger

2UUL PC01

Description:
True 4K UHD Camera with 60 Megapixel 1/2" 1/2.7" Sensor HDMI USB Type-C Port for industrial stereo trinocular microscopes and C-mount adapters. Professional imaging with true 4K 60MP high resolution and enhanced clarity. Equipped with advanced Sony sensors, with multi-resolution recording, customizable cross-line functionality and support for 11 languages, very suitable for mobile phone repair, electronic motherboard welding repair, industrial testing, research and various high-precision tasks

Option:
Option1: 4K-A1: HDMI + USB Port + TF Card.
Option2: 4K-A2: HDMI + USB Port + TF Card.
Option3: 4K-A3: HDMI + USB Port + TF Card.
Option4: 4K-A4: HDMI + USB Port + TF Card.
Option5: 4K-U1: HDMI +USB Port + U Disk.
Option6: 4K-C1: HDMI + TypeC + TF Card.

Features:
1. High-resolution photos: 60MP(10368×5888) images are directly stored to TF or USB drive for easy use.
2. Sony original chip: Provides enhanced image processing and high sensitivity for excellent results.
3. Precise cross-line support: Configurable 32-line overlay for precise alignment and measurement.
4. Compact and lightweight: Ergonomic design, easy to install and carry.
5. Versatile connection: Multiple interface options (HDMI, USB, Type-C, TF card) for flexible integration.
6. 4K UHD resolution: Output 4K@30FPS and 1080p@60FPS via HDMI and USB to capture fine details clearly.
7. Durable structure: Industrial-grade materials ensure stability and service life.
8. Energy-saving design: With progressive scanning and low power consumption, it can provide reliable performance.
9. Customizable imaging: Adjust brightness, contrast, sharpness, and saturation for tailored results.
10. Multi-language support: Includes 11 language options for global usability.
11. Good quality and low price, economical and affordable 4K camera.

4K-A1, 4K-A2,  4K-A3, 4K-A4 Camera Parameter:
Interfaces: HDMI + USB + TF Card.
Dimensions (LWH): Model 66: 66*66*33mm.
Sensor Size: 1/2.7" Inch.
Power supply mode: 12V/USB.
HDMI output of display resolution: 4K@30FPS, 1080p@60FPS.
USB-PC output of display resolution: 4K@30FPS, 1080p@30FPS.
Photo: 60MP(10368*5888).
Udisk video resolution: 4K@30FPS, 1080p@30FPS.
OSD language: 11 Languages.
Cross line: Supports 32 horizontal / vertical lines, adjustable color / line width.
Lens: CS.
Working current: 190mA.
Pixel array: 4K(3840*2160).
Photo: 60MP（10368*5888).
Scanning mode: Progressive scan.
Shutter mode: Electronic shutter.
Dynamic range: 69dB.
S/N radio: 40dB.
AWB mode: One-time White Balance / Manual / Auto.
Support: HDR, B/W, negative, mirror flip, freeze, manual set, bright, contrast, sharp, saturation.

4K-C1 Parameter:
Interfaces: HDMI + Type-C + TF Card.
Dimensions (LWH): Model 66: 42*42*46mm.
Sensor Size: 1/2.7" Inch.
Power supply mode：12V/USB.
HDMI output of display resolution: 4K@30FPS, 1080p@60FPS.
USB-PC output of display resolution: 4K@30FPS, 1080p@30FPS.
Photo: 60MP(10368*5888).
Udisk video resolution: 4K @30FPS, 1080p@30FPS.
OSD language: 11 Languages.
Cross line: Supports 32 horizontal / vertical lines, adjustable color / line width.
Lens: CS.
working current: 190mA.
Pixel array: 4K(3840*2160).
Photo: 60MP(10368*5888).
Scanning mode: Progressive scan.
Shutter mode: Electronic shutter.
Dynamic range: 69dB.
S/N radio: 40dB.
AWB mode: One-time White Balance / Manual / Auto.
Support: HDR, B/W, negative, mirror flip, freeze, manual set, bright, contrast, sharp,saturation.

4k-U1 Parameter:
Interfaces: HDMI + USB Type-C + USB Drive.
Dimensions (LWH): Model 66: 66*66*40mm.
Sensor Size: 1/2" Inch.
Power supply mode: 12V/USB.
HDMI output of display resolution: 4K@30FPS, 1080p@60FPS.
USB-PC output of display resolution: 4K@30FPS, 1080p@30FPS.
Photo: 60MP(10368*5888).
Udisk video resolution: 4K @30FPS, 1080p@30FPS.
OSD language: 11 Languages.
"Cross line": Supports 32 horizontal / vertical lines, adjustable color / line width.
Lens: CS.
Working current: 190mA.
Pixel array: 4K(3840*2160).
Photo: 60MP(10368*5888).
Scanning mode: Progressive scan.
Shutter mode: Electronic shutter.
Dynamic range: 69dB.
S/N radio: 40dB.
AWB mode: One-time White Balance / Manual / Auto.
Support: HDR, B/W, negative, mirror flip, freeze, manual set, bright, contrast, sharp, saturation.

4K Microscope Camera For Stereo Trinocular Microscope

 4K-A1

4K-A2

4K-A3

4K-A4

 4K-U1

4K-C1

Description
500 Electronic Projects for beginners & Inventors with tested circuits.Your Ultimate Free Resource for Hands-On Electronics Learning! The "500 Electronics Projects" PDF book is a must-have for anyone looking to explore and innovate in the world of electronics. Packed with an impressive array of projects and circuit designs, this book offers insights into electronics concepts and hands-on applications. From foundational circuits to advanced systems, it’s a perfect guide for students, hobbyists, and professionals eager to build and experiment.

"Exploring the World of Creativity and Technology: 500 Electronic Projects to revolutionize innovationand Learning" - --Share our website to your friends! Get Our Surprising Gift!

What You’ll Find in the Book:
Extensive Range of 500 Projects:

A huge collection of projects, covering a wide range of applications and categories, from basic circuits like LED controllers and voltage regulators to more complex systems like wireless communication modules and microcontroller-based projects.
Detailed Circuit Diagrams and Schematics:

Every project includes detailed circuit diagrams and schematics, helping you to understand the wiring and connections necessary for each design. Components are clearly labeled to make it easy for you to gather materials and start building.
Step-by-Step Instructions:

Each project is broken down into easy-to-follow steps, with explanations on how each component functions within the circuit. This makes it accessible for beginners while still being comprehensive enough for advanced users.
Wide Range of Topics Covered:

Power Supplies and Converters: Learn how to design and build various types of power supplies, including AC-to-DC converters, adjustable power supplies, and voltage regulators.
Audio Circuits: Explore audio amplifiers, equalizers, and sound effect circuits that allow you to manipulate and understand sound electronically.
Light and LED Projects: From basic LED blinkers to advanced light-sensitive circuits, these projects help illustrate key concepts in lighting control and photonics.
Microcontroller-Based Projects: Delve into microcontroller (Arduino, PIC, etc.) projects that allow for programmable functions and automation.
Sensor and IoT Projects: Work on Internet of Things (IoT) and sensor-based projects that introduce you to automation, remote sensing, and data collection.
Robotics and Motor Control: Build your own robots and motor control systems, learning the basics of motion, feedback control, and sensor integration.
Wireless Communication: Understand wireless technologies by building projects using RF, Bluetooth, and infrared modules.
Suitable for All Levels:

Beginners can start with simple circuits like LED flashers, voltage testers, and basic amplifiers, building a solid foundation in electronics.
Intermediate learners will find projects like oscillators, timers, and digital counters to expand their skillset.
Advanced users can dive into complex designs involving microcontrollers, data acquisition systems, and programmable circuits.
Practical Theory:

In addition to the hands-on projects, this book provides theoretical explanations of core electronics principles, such as Ohm’s Law, Kirchhoff’s Laws, transistor operation, and AC/DC fundamentals. This makes it easy to understand the principles behind each project and apply them to future designs.
Project Applications:

Each project is designed with real-world applications in mind, from home automation systems and personal gadgets to educational tools and prototype models. This versatility allows you to directly apply your knowledge to practical uses.
Why Download This Book?
This free resource offers a treasure trove of information and practical experience that will inspire and guide you as you deepen your knowledge of electronics. Whether you’re exploring for fun or building a professional skillset, "500 Electronics Projects" can help you:

Build a Strong Foundation: Starting with the basics, you’ll quickly gain the skills needed to tackle more advanced topics.
Expand Your Project Portfolio: A great resource for students and hobbyists looking to create a portfolio of diverse electronics projects.
Save Time and Effort: With clear diagrams, instructions, and materials lists, this book saves you the time it would take to design and troubleshoot projects from scratch.
Stay Engaged with Challenging Designs: Advanced users can benefit from challenging designs, which can also be adapted and expanded upon to suit personal or professional projects.
Get started today and open up a world of creativity and problem-solving in electronics with "500 Electronics Projects." This book provides the roadmap you need to move from theory to practice, empowering you to create, experiment, and innovate.

500 Best Electronics Projects Electronic Book for Beginners

Leave your email box

0ML ESD dispenser Plastic solvent bottle Stainless steel needle Tip leak proof needle bottle for mobile phone screen or frame Glue removal repair. 60ML ESD Antistatic Solvent Bottle Safe Flux Dispenser With Stainless Steel Needle Antistatic Glue Dropper.

Antistatic ESD dispenser Plastic solvent bottle Liquid Bottle have Blue & Yellow 2 Colors Randomly Available, Especially suitable for mobile phone screen frame Precision glue dispensing Electronic PCB Board Cleaning repair.

Features:
1. Antistatic solvent bottle 60ML high specification, recyclable, easy to use.
2. With stainless steel needle, durable, strong sealing and small and portable.
3. ESD Safe antistatic solvent bottle, hardened and thickened, blue and yellow 2 colors randomly delivered.
4. Suitable for electronic manufacturing and clean room environment, because electrostatic discharge may damage sensitive components.
5. 60ml ESD alcohol bottle dispenser, with stainless steel needle antistatic glue dropper, for mobile phone screen frame electronic PCB board cleaning repair.

Package includes :
1pc x Antistatic Solvent Bottle - Empty (60ml).
1pc x Needle Tip.

60ML ESD Dispenser Plastic Solvent Bottle With Needle Tip

Random Color

Description
AMAOE SF1 0.12mm BGA Reballing Stencil Comprehensive Tin Planting Net for Microsoft Surface Chips soldering repair. Amaoe Surface Pro X CPU SQ2 Stencil Steel Mesh 52*60mm. AMAOE EC chip MRT633SFF0B reballing stencil for Surface Pro 7+/8/9 and Laptop 4/5 IC soldering repair.

Options:
1. Amaoe EC chip-MRT633SFFOB reballing stencil: 0.12MM 52X60MM BGA Reballing Stencil, suitable for Surface Pro7+/8/9, Laptop4/5.
2. Amaoe SF:1 stencil: 0.12MM Surface series strong magnetic integrated network, For QCA6 174A/BGA178/IT8528VG/BGA153/BGA200/GP213/X026B601/ROHM992/WCSAX201/M22J9VDC/MARVELL/LPC54S001J/KUS020203M-B000/SSDPEBKF128G7/WiFi IC/95AG101/11E37/X904163/M17P8V/X904169/QIC1832-898B /ALC3269.
3. Amaoe Surface Pro X CPU SQ2: 0.12MM 52X60MM BGA Reballing Stencil.

Features:
1. Made of durable chrome vanadium steel to ensure long-term use and precision.
2. The template can be used in a variety of repair scenarios and has a wide range of applications.
3. Designed for a variety of devices, compatible with Surface Pro models, etc.
4. Surface series strong magnetic integrated net 012MM.
5. Suitable for screen LCD IC tinning template steel mesh repair.

Package List:
1 x Surface BGA Reballing Stencil (optional).

Aamoe EC Chip BGA Reballing Stencil for Chip Soldering

 Aamoe SF:1

Aamoe EC Chip-MRT633SFFOB

Aamoe Surface Pro X CPU SQ2

Description
AiXun T208 Mini Soldering Station with C080 Soldering Iron Tips for mobile phone repair, such as Phone motherboard welding repair, electronics PCB CPU Chip soldering and desoldering, jump wire, ect. Portable AiXun T208 80W Smart Electric Wireless Soldering Iron has a 0.96-inch LCD screen, Type-C charging port, rapid heating, tinning in 2 seconds and auto sleep function.

Option:
1. AIXUN T208 standard set: T208 Mini Soldering Iron Pen+C080-024 Knife Tips.
2. AIXUN T208 full set: T208 Mini Soldering Iron Pen+3pcs C080 Iron tips.
3. AIXUN C080 Soldering Iron Tips (optional):
- C080-024 Knife (K024-Knife head)
- C080-010 Straight (I010-Straight head)
- C080-020 Curved (S020-Curved head)

Features:
1. Easy to carry, fast charging and ready to use, built-in 6-axis gyroscope, automatic standby, safe and convenient.
2. 0.96-inch LCD screen, temperature and power are clearly visible, and come standard with C080 soldering tip.
3. USB communication, supports remote OTA upgrade, unlimited functions expansion, the body comes with three buttons, and controls easily.
4. High temperature resistant materials, no burning hot under normal use for 1 hour, high temperature resistant silicone tip protector for convenient storage.

Product Parameters:
Product Name: AiXun T208 Portable Smart Soldering Station
Input voltage:  DC9V-12V-15V-20V (refer to the protocol of the charging device)
Communication: USB
Display type: 0.96-inch LCD screen
Rated power: 18W-60W (adjust manually), maximum power 80W
Compatible heating core:  C080
Standard packaged heating core: C080 - blade tip
Material: Anti-scald silicone tip protector (blue)+injection molded body (spray black)
Dimensions: Soldering handle (not include tip) with protector: Length 199.8mm x Width 20.8mm x Height 21.6mm
Soldering handle (not include tip): Length 149.7mm x Width 20.8mm x Height 21.6mm
Net weight: 249G
Bare weight: 45G

AiXun T208 Portable Soldering Iron Station for Motherboard Repair

T208 standard 1 tip

T208 full 3 tips

C080-024 K tip

C080-010 Straight tip

C080-020 Curved tip

Description
AiXun T400 320W Smart Soldering Workstation compatible with T225 handle and 4 types of soldering iron tips C030-C080-C150-C250. Supports WiFi OTA upgrade and can connect up to six devices with the 6-in-1 docking station at the same time, for high-precision PCB component welding and large surface repair.

Features:
1. 320W rated power, toroidal transformer, AC pure isolation is suitable for various high-precision components and large parts surface welding scenarios.
2. With EB01 docking station, it supports connecting up to six devices at the same time.
3. Compatible with AiXun 4 in1 smart soldering handle T225 and 4 types of soldering iron tips C030-C080-C150-C250.
4. Built-in gyroscope for gesture control, which enables intuitive operation and enhances the interaction between users and devices.
5. Equipped with a new seven-core metal dormant seat, made of high-quality aluminum alloy, with excellent heat dissipation performance, sturdy and durable.
6. AI intelligent voice control, can be connected to BS08 voice central control.
7. Rapid heating without overheating, repeated heating without cooling.
8. With ES02 range hood, 4000 rpm high-speed brushless motor.
9. Double filtration system, high-precision filtration, one-click dust removal, smoke removal, and odor removal.
10. Equipped with WiFi+Bluetooth module.

Parameters:
Name: Smart Soldering Workstation.
Brand: AiXun.
Model: T400.
Fuse: 3A.
Input voltage: 230V-50Hz.
Rated power: 320W.
Compatible handle model: T225.
Compatible soldering tips: C030-C080-C150-C250.

Packing List:
1X T400 host.
1X Soldering station metal dormant seat.
1X Double-headed seven-core aviation plug connection cable.
1X Branch line rod.
1X Screw.
1X Four-in-one smart soldering pen T225.
3X Welding head.
1X Power cord.
1X Ground wire.
1X Instruction card.
1X Certificate of conformity.

AiXun T400 6in1 Smart Soldering Workstation Motherboard Repair

AiXun T400

Description
Amaoe A18/A18 Pro CPU planting tin platform with A18/A18Pro CPU lower layer 0.12mm stencil and tin scraping blade for iPhone 16/16 Plus/16 Pro/16 Pro Max CPU soldering repair. Amaoe iPhone 16/16 Pro CPU reballing platform with universal magnet base and A18/Pro positioning plate, A18 stencil and A18 Pro stencil.

Option:
1. Amaoe A18 CPU tin planting platform for iPhone 16/16 Plus.
2. Amaoe A18 Pro CPU reballing platform for iPhone 16 Pro/16 Pro Max.

Amaoe A18 CPU reballing platform list:
1x Universal magnet base.
1x A18/Pro positioning plate.
1x A18 lower layer soldering stencil(0.12mm).
2x tin scraping blades.

AMAOE A18 Pro reballing platform list:
1x Universal magnet base.
1x A18/Pro positioning plate.
1x A18 Pro lower layer reballing stencil(0.12mm).
2x tin scraping blades.


Amaoe A18 + A18 Pro CPU Planting Tin Platform for iPhone 16

A18 CPU Planting Tin Platform

A18Pro CPU Planting Tin Platform

A18 Lower Layer stencil

A18Pro Lower Layer stencil

Description
AMAO GCJ:1 0.12mm Tin-planting steel mesh lawnmower equipment GD32F450 MGZ2067HC3 BGA reballing stencil. Heat dissipation holes with anti-bulging steel mesh design.

Features:
1. AMAOE GCJ Series BAG reballing stencil for Lawn Mower GD32F450 MGZ2067HC3.
2. Heat dissipation holes with anti-bulging steel mesh design.
3. 0.12MM thickness tin-planting mesh.
4. AMAOE GCJ:1 reballing stencil: suitable for 3122EH, GD32F103, BGA153, CH9101H, 7689, GD32F450, MGZ2067HC3, 9270 chips soldering tin planting repair.

AMAOE GCJ Lawn Mower GD32F450 MGZ2067HC3 Tinning Platform

GCJ:1

Description
ATTEN GT-1028 Programmable Intelligent Internet of Things Hot Air Desoldering Station Digital Display BGA Rework Station. Atten GT-1028 1300W High Power Hot Air Rework Station with Vacuum Pick-Up Tool for phone PCB motherboard soldering repair.

Atten GT-1028 1300W  Hot Air Desoldering Station is a professional intelligent rework station with vacuum pick-up tool. Components can be extracted after desoldering, built-in brushless fan, long use life, and low noise. Support control the switch on and off of the smoke purifier.

Features:
1. Large TFT color screen, more convenient to set and monitor parameters.
2. 1300W pluggable ceramic heater, heating fast,  PID algorithm temperature control, accurate, and stable temperatur.
3. Infrared temperature calibration function,temperature curve setting function.
4. 3 sets of shortcut air volume/temperature to simplify operations, it can be controlled by an external pedal. Built-in RS-485 communication interface, supports Iot functions.

Specification:
Model: GT-1028.
Rated operating voltage: AC 110V/220V.
Power: 1330W(220-240V)/1000W(110-120V).
Fuse: T8A(AC 250V)/T12A (AC 125V).
Temperature Range: 100℃~500℃/212℉~932℉.
Air Volume Range: 1%~100%.
Timing Time: 10~900s (Can be turned off).
Temperature unit: ℃/℉, default ℃.
Vacuum pressure: -60Kpa.
Airflow: 120L/Min (Max).
Multiple alarm and protection functions: Heater open circuit alarm, sensor fault alarm, zero crossing signal alarm, SCR damage alarm, over-temperature protection alarm.
Password protection function: Available (Off by default).
Alarm function: Available (On by default).
User temperature compensation: ±50℃/±90℉.
Multiple languages for user interface: Chinese/English.
Heating power display: 5 dynamic power bars.
Temperature adjustment step: Long press for 10 units adjustment, short press for 1 unit adjustment.
Air volume adjustment step: Long press for 2 units adjustment, short press for 1 unit adjustment.
Rapid temperature air volume time: 3 groups of temperature/air volume/time, can be called quickly.
Working conditions: Temperature 0℃~40℃; Relative humidity<85%RH.
Dimension: 230*142*145mm.

Package includes:
1 x Atten GT-1028 Desoldering Station.
1 x Power Cord.
1 x Hot Air Gun Handle.
3 x Hot Air Gun Nozzle.
1 x Hot Air Gun Holder.
1 x USB Cable (A To B).
1 x Vacuum Pen (Included Tool Box).
2 x Bent Suction Nozzle.
2 x Straight Suction Nozzle.
12 x Suction Disc.

Atten GT-1028 Intelligent Digital Display Hot Air Gun Rework Station

110V US Plug

220V EU Plug

Description
Aweshine TS-01 SIM card tester detects Phone/Pad SIM card slots without disassembly, and detects the single board removed from the mobile phone and directly collects the resistance value of the device diode gear. Aweshine TS-01 Universal SIM card slot signal detection tool.

Features:
1. Single board detection, no need for power supply, with the built-in battery in the tester, it's able to detect the single board that was removed from the phone, and collect the resistance value of the diode gear of the device directly.
2. Detecting without dismantling plug and play, industry-leading plug and play technology, detecting SIM card slot without disassembling the phone.
3. Feedback the test results through the breathing light when the phone is booted up, and the collected data is displayed on the screen when the phone is shut down, diverse and convenient.
4. Exclusive customized services, support customization of SIM card holders adaptor for all electronic products on the market, providing customized services for SIM card holders of different sizes to meet the personalized needs of each customer.
5. Extraordinary and leading quality, the body is made of composite materials, which are sturdy, durable and fashionable. The internal PCB embodies the essence of circuit design with exquisite craftsmanship and innovative artistry, ensuring excellent performance and becoming a benchmark in the industry.
6. Minimalism of Aweshine, the device only has one button, without any complicated operations. One click detection, plug and play, quickly collects the resistance value of the diode gear, obtaining data through breathing light or the clear screen display directly, demonstrating the convenience and intelligence of modern technology.
7. The 0.84-inch OLED HD display screen brings clear and delicate visual enjoyment with its excellent performance and single color design, showcasing the perfect combination of modern technology and minimalist aesthetics.
8. The classic AS design style leads the industry trend with fashionable and unique appearance, injecting extraordinary aesthetic charm and intelligent manufacturing spirit into every AS product.
9. Mini body with excellent battery life,A 500mAh lithium battery is included in the compact body, supporting up to 12 hours of continuous operation, no need to charge frequently, the long-lasting power provides you with a worry free companion.
10. Splendid portable design, the exquisite and compact body showcases the portability of technology on the go. lt can be easily carried in a pocket or bag, convenient and practical.

Product Parameters:
Model: AWESHINE TS-01 SIM Card Tester.
Display type: LED
Input voltage: 5V1A 50%
Max input voltage: 3W
Light: Yellow light flashing
Package dimensions:119*71.5*20mm

AWESHINE AS-TS01 SIM Card Tester For SIM Card Testing

AWESHINE TS01

Description
The most common type of Soldering Microscope Heads, Commonly Used SZM7X45 7X-45X Continuous Zoom Trinocular Stereo Microscope Head Replacement. DG7X60 7X-60X/ST8X50 8X-50X /SZ6745 6.7X-45X 360 Degree Rotatable 45 degree Inclined Binocular Microscope Head Replacement. Suitable for cell phone repair, motherboard repair, soldering desoldering PCB observation.

SZM7X45 Parameters:
Type: Continuous zoom trinocular stereo microscope
Total Magnification: Original 7X~45X (Enlarged to 90X with 20X eyepiece)
Observation tube: Trinocular
Eyepiece: WF20X
Objective lens: 0.7X~4.5X continuous magnification

DG7X60 Parameters:
Head: 360 degree rotatable 45 degree inclined binocular
Eyepieces: WF10X/22MM
Zoom Magnification:0.7-6x
Field of View:31.4mm-3.7mm
Magnification:7x-60x
Working Distance:120mm
Installation diameter: 76mm
Adjustable eyepiece:Standard WF10X22,High angle wide angle eyepiece, provide convenience for observers wearing glasses

SZ6745 Parameters:
Head: 45-degree inclined 360-degree swiveling binocular
Eyepiece: 30mm extreme wide field high-eye point WH10X/22
Objective: 0.67-4.5X
Zoom Range: 6.7:1
Diopter Adjustment: ±5dp
Interpupillary Distance: 2-3/4" - 2-15/16"(47-75mm)
Field of View: 1-3/8" (35mm)
Working Distance: 4" (100mm)
Head Mounting Size: 3" (76mm) in diameter
Accessory Mounting Size: 1-7/8" (48mm female thread) in diameter

ST8X50 Parameters:
Head: 45 degree inclined 360 degree swiveling binocular
Eyepiece: 30mm extreme widefield focus-adjustable 10X/22
Objective: 0.8X-5.0X
Diopter Adjustment: +/-5dp
Interpupillary Distance: 2-0" - 2-15/16"(52-75mm)
Working Distance: 4.5" (115mm)
0.4X reduction lens

Chinashopphonefix

Products

2UUL PC01 Power Max Electric Rubik's Cube Multi-Port Charger

$40.00

4K Microscope Camera For Stereo Trinocular Microscope

$48.00

500 Best Electronics Projects Electronic Book for Beginners

$0.01

60ML ESD Dispenser Plastic Solvent Bottle With Needle Tip

$0.88

Aamoe EC Chip BGA Reballing Stencil for Chip Soldering

$2.90

AiXun T208 Portable Soldering Iron Station for Motherboard Repair

$8.00

AiXun T400 6in1 Smart Soldering Workstation Motherboard Repair

$290.00

Amaoe A18 + A18 Pro CPU Planting Tin Platform for iPhone 16

$15.00

AMAOE GCJ Lawn Mower GD32F450 MGZ2067HC3 Tinning Platform

$2.50

Atten GT-1028 Intelligent Digital Display Hot Air Gun Rework Station

$479.99

AWESHINE AS-TS01 SIM Card Tester For SIM Card Testing

$19.00

Common Stereo Microscope Head For Electronic Repair

$90.00

Contacts

phonefix ro

Locations

Details
